Stainless Steel 347/347H Sheets & Plates

  • Home
  • Stainless Steel 347/347H Sheets & Plates

347/347H Stainless Steel Plates, Stainless Steel S34709 Plates, Buy Large Or Small Quantity Stainless Steel 347 Sheet, SS 347H Shim Sheets, UNS S34700 Sheets, 347H Stainless Steel Perforated Sheet Supplier in Mumbai, India.

SS 347 Coils, Werkstoff Nr. 1.4550 Sheets, Stainless Steel 347 Strip, ASTM A240 SS 347 Hot Rolled Plate Manufacturer, Stainless Steel 1.4961 Cold Rolled Plates, Stainless Steel 347 Chequered Plate, 347H SS Foils Manufacturer in India.

Stainless Steel 347/347H Sheets & Plates

Jade Special Metals is a known exporter and trader of SS 347 / 347H Sheets & Plates, which are designed by using high grade factor inputs and advanced technology in compliance with defined industry standards. These Stainless Steel 347 Sheets are highly appreciated for superior finish, compact designs, rigid construction, corrosion & chemical resistance and durability. In Stainless Steel 347 Plates, solution treatment is carried out at temperatures and for times sufficient to produce the required properties and the material is then cooled to prevent 475-degree C embrittlement. Providing higher strength than both austenitic and 22 percent Cr, Stainless Steel 347 Coils is suited to a variety of applications in industries such as Chemical Processing, Oil & Gas, and Marine environments. Stainless Steel 347H Sheets is considered to feature resilient to pitting, high strength, SCC, erosion weathering and oxidization fatigue, crevice rust and potency weldability. Stainless Steel 347H Plates has an excellent microstructure which contributes to their high strength and high resistance to stress corrosion cracking. Stainless Steel 347H Coils, Stainless Steel 410l Plate is often used in Chemical Process Industry, such as for Nitric Acid Processes, Polypropylene Production, Caustic Evaporators, Equipment Handling Organic and Fatty Acids. Stainless Steel UNS S34700 Sheets & Plates exhibits a low coefficient of thermal expansion and higher heat conductivity than austenitic steels and is suitable for working temperatures up to 300 Degree C.

Stainless Steel 347/347H Sheets & Plates Specifications

Standard : ASTM A240 / ASME SA240
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4 mm To 100 mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Form : Sheets, Plates, Coils, Slatting Coils, Perforated Coils
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

“Contact Jade Special Metals today with your requirement for 347 Stainless Steel Sheet and 347H SS Plates. We assure you of the best quote.

347 / 347H Stainless Steel Sheets & Plates Equivalent Standard Grade

STANDARD WERKSTOFF NR. UNS JIS GOST EN
SS 347 1.4550 S34700 SUS 347 08Ch18N12B X6CrNiNb18-10
SS 347H 1.4961 S34709 SUS 347H X6CrNiNb18-12

Stainless Steel 347 / 347H Sheets & Plates Inventory

Perforated Sheets
Stainless Steel 347/347H Perforated Sheets
Chequred Plates
Stainless Steel 347/347H Chequred Plates
Shim Sheets
Stainless Steel 347/347H Shim Sheets
Coils
Stainless Steel 347/347H Coils
Foils
Stainless Steel 347/347H Foils
Strips
Stainless Steel 347/347H Strips

Stainless Steel 347/347H Sheets & Plates Chemical Composition

Grade C Mn Si P S Cr Cb Ni Fe
SS 347 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 17.00 – 20.00 10xC – 1.10 9.00 – 13.00 62.74 min
SS 347H 0.04 – 0.10 2.0 max 1.0 max 0.045 max 0.030 max 17.00 – 19.00 8xC – 1.10 9.0 -13.0 63.72 min

SS 347/347H Sheets & Plates Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1454 °C (2650 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %
8.0 g/cm3 1454 °C (2650 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Available Stock of ASTM A240 Stainless Steel 347 / 347H Sheets & Plates

  • Stainless Steel 347 Shim Sheets
  • SS 347H Circles
  • 347 Stainless Steel Plain Sheets
  • 347 Stainless Steel Foils
  • UNS S34700 Polished Plates
  • WERKSTOFF NR. 1.4550 Perforated Sheet
  • ASTM A240 347H Stainless Steel Sheet
  • Stainless Steel 347 Sheet Cut To Size
  • Stainless Steel 347H Sheet #4 Finish
  • 347 SS Cold Rolled Plates
  • ASTM A240 Type 347 Plate 2B Finish
  • 347H Stainless Steel Plate Mill Finish
  • UNS S34709 Plates
  • WERKSTOFF NR. 1.4961 Shim Sheets
  • ASTM A240 AISI 347H Coils
  • ASTM A240 347H SS Slitting Coil
  • Stainless Steel 347H CR Sheet
  • Stainless Steel 347 Strips
  • 347H Stainless Steel #4 Finish Sheets
  • 347 Stainless Steel Foils
  • UNS S34700 Sheet Supplier
  • WERKSTOFF NR. 1.4550 HR Plates
  • 347H Austenitic Stainless Steel Sheet
  • SS 347H #8 Finish Plates
  • SS 347 Plate Manufacturer
  • 347H Stainless Steel Laser Cutting Sheet
  • Jindal Stainless Steel 347 Sheets
  • 347 Stainless Steel Sheets Distributor
  • UNS S34709 Plates Exporter
  • WERKSTOFF NR. 1.4961 CR Sheets
  • ASTM A240 Type 347 Sheet and Plate
  • ASTM A240 347H Stainless Steel Plate
  • 1.4961 Stainless Steel Perforated Sheet
  • SS 347H 2B Finish Plates Stockist
  • AISI 347 Sheets
  • Stainless Steel 347H Sheets Price

Applications of Stainless Steel 347 / 347H Sheets & Plates

  • Pipeline Engineering
  • Marine Industry
  • Chemical Industry
  • Oil & gas industry
  • Mechanical Engineering
  • Plant Engineering
  • Petrochemical Industry
  • Power Industry
  • Aerospace
  • Food Processing Industry
Industry

We maintain ready stock of 347 Stainless Steel Sheet, SS 347 Plates, SS 347H Coils, 347 SS Shims, Stainless Steel 347 Strips and 347H SS Foils. Get in touch with us with your requirement for quick quote.
