Buy Large Or Small Quantity Incoloy 800 Sheet, Incoloy N08800 Plates, Incoloy 800 Shim Sheets, 800HT Incoloy Alloy Plates, UNS N08810, N08811 Sheets, 800H Inconel Perforated Sheet Supplier in Mumbai, India.
Inconel 1.4876 Cold Rolled Plates, Incoloy 800H Strip, ASTM B409 Incoloy 800HT Hot Rolled Plate Manufacturer, JIS NCF 800 Plate, Alloy 800 Coils, Werkstoff Nr. 1.4958, 1.4859 Sheets, Inconel Alloy 800 Chequered Plate, 800H Incoloy Alloy Foils Manufacturer in India.
Jade Special Metals is an acknowledged distributor of Inconel Alloy 800 / 800H / 800HT / Sheets & Plates, which is the highest strength pure unalloyed with high oxygen and extra high strength. The deprived shear power of Incoloy 800 Sheets makes it disagreeable for bone plates or screws. Incoloy 800 Plates is most usually used for jet engine and airframe applications that require excellent weldability, strength and stability at high temperatures. Incoloy 800 Coils has had its prolonged use for propellant containment and liquid gas for space and rockets vehicles. Incoloy 800H Sheets is a soaring potency alloy that is most usually used in jet engine and airframe applications. Incoloy 800H Plates has excellent weldability and displays oxidation resistance and stability at high temperatures in the range of 600 Deg F to 1000 Deg F. Incoloy 800H Coils is outstanding, particularly when uninterrupted contact by means of bone or tissue is essential. Incoloy 800HT Sheets is appreciated for its tough constriction, high durability, ease of installation and low maintenance. Incoloy 800HT Plates are forgings and sheet metal parts such as jet turbine compressor blades, ducting, and steam turbine blades. Incoloy 800HT Coils provides corrosion resistance, strength and fatigue characteristics that compare favorably to those of nickel and steel alloys. Incoloy UNS N08800 Sheets & Plates has outstanding corrosion resistance and soaring impact durability. Incoloy UNS N08810 Sheets & Plates is usually the material of select for any function where easiness of formability is essential.
Quick Section Links
- Incoloy 800 / 800H / 800HT Sheets & Plates Specifications
- Incoloy 800 / 800H / 800HT Sheets & Plates Equivalent Standard Grade
- Incoloy 800 / 800H / 800HT Sheets & Plates Inventory
- Incoloy 800 / 800H / 800HT Sheets & Plates Chemical Composition
- Incoloy 800 / 800H / 800HT Sheets & Plates Mechanical Properties
- Available Stock of ASTM B409 Incoloy 800 / 800H / 800HT Sheets & Plates
- Applications of Incoloy 800 / 800H / 800HT Sheets & Plates
Incoloy 800 / 800H / 800HT Sheets & Plates Specifications
| Standard : | ASTM B409 / ASME SB409 |
| Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness : | 0.3 mm to 120 mm |
| Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Form : | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Finish : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
“Contact Jade Special Metals today with your requirement for Incoloy 800 Sheet and Alloy 800H Plates. We assure you of the best quote.
Incoloy 800 / 800H / 800HT Sheets & Plates Equivalent Standard Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 |
Incoloy 800 / 800H / 800HT Sheets & Plates Inventory
Incoloy 800 / 800H / 800HT Perforated Sheets
Incoloy 800 / 800H / 800HT Chequred Plates
Incoloy 800 / 800H / 800HT Shim Sheets
Incoloy 800 / 800H / 800HT Coils
Incoloy 800 / 800H / 800HT Foils
Incoloy 800 / 800H / 800HT Strips
Incoloy 800 / 800H / 800HT Sheets & Plates Chemical Composition
| Grade | C | Mn | Si | Al | S | Cr | Cu | Ni | Fe |
| Incoloy 800 | 0.10 max | 1.50 max | 1 max | 0.15 – 0.60 | 0.015 max | 19.0-23.0 | 0.75 max | 30.0-35.0 | 39.5 min |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1 max | 0.15 – 0.60 | 0.015 max | 19.0-23.0 | 0.75 max | 30.0-35.0 | 39.5 min |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1 max | 0.15 – 0.60 | 0.015 max | 19.0-23.0 | 0.75 max | 30.0-35.0 | 39.5 min |
Incoloy 800 / 800H / 800HT Sheets & Plates Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Available Stock of ASTM B409 Incoloy 800 / 800H / 800HT Sheets & Plates
- Incoloy 800 Shim Sheets
- Alloy 800H Circles
- 800 Inconel Plain Sheets
- 800HT Incoloy Alloy Foils
- UNS N08800 Polished Plates
- WERKSTOFF NR. 1.4876 Perforated Sheet
- ASTM B409 800 Incoloy Sheet
- Inconel 800H Sheet Cut To Size
- Incoloy 800 Sheet #4 Finish
- Alloy 800HT Cold Rolled Plates
- ASTM B409 Type 800 Plate 2B Finish
- 800HT Inconel Plate Mill Finish
- UNS N08810 Plates
- WERKSTOFF NR. 1.4859 Shim Sheets
- ASTM B409 Alloy 800H Coils
- ASTM B409 Alloy 800 Slitting Coil
- Inconel 800HT CR Sheet
- Incoloy Alloy 800 Strips
- 800 Incoloy #4 Finish Sheets
- 800HT Incoloy Alloy Foils
- UNS N08811 Sheet Supplier
- WERKSTOFF NR. 1.4958 HR Plates
- 800H Inconel Sheet
- Alloy 800 #8 Finish Plates
- Incoloy® Alloy 800 Plate Manufacturer
- 800HT Incoloy Laser Cutting Sheet
- Incoloy 800 Sheets
- 800HT Incoloy Sheets Distributor
- UNS N08800 Plates Exporter
- WERKSTOFF NR. 1.4876 CR Sheets
- ASTM B409 Type 800 Sheet and Plate
- ASTM B409 800H Incoloy Plate
- 1.4859 Incoloy Perforated Sheet
- Alloy 800 2B Finish Plates Stockist
- Incoloy® Alloy 800 Sheets
- Inconel 800HT Sheets Price
Applications of Incoloy 800 / 800H / 800HT Sheets & Plates
- Pipeline Engineering
- Marine Industry
- Chemical Industry
- Oil & gas industry
- Mechanical Engineering
- Plant Engineering
- Petrochemical Industry
- Power Industry
- Aerospace
- Food Processing Industry
We maintain ready stock of 800 Incoloy Sheet, Alloy 800HT Plates, Inconel 800 Coils, Incoloy Alloy 800 Shims, Incoloy 800H Strips and 800 Inconel Foils. Get in touch with us with your requirement for quick quote.
